HTL110Y Large-Scale CNC Turning Center with Φ700mm Max Swing Over Bed 10 m/min Max Cutting Feed Rate and 65 mm Spindle Bore

The HTL Series from ShangJie PM is engineered for long-shaft and extended-part turning applications. Featuring a heavy-duty slant-bed design and powerful spindle system, these CNC lathes offer exceptional rigidity, precision, and smooth chip evacuation during high-speed, long-cycle operations. Ideal for machining deep-hole parts, rollers, pipes, and extended rods, the HTL Series meets the needs of industries like oilfield equipment, automotive axles, and mechanical transmission. With programmable servo turret control and optional steady rests, it ensures both stability and accuracy in complex long-part production.

The HTL series is a large-scale CNC turning center, specially designed for large and long shaft products. It features an ultra-wide integral bed, a 45° inclined saddle, and large-sized roller linear guides and ￠50mm precision-grade ball screw. This provides sufficient machine rigidity, enabling it to handle various machining tasks and maintain bed accuracy for a long time.

By applying finite element analysis (FEM), the shape and position of the reinforcing ribs in the castings are optimized to achieve the best bed strength, making the bed structure more suitable for heavy cutting and extending the tool's service life.
