ST32 CNC Turning Center With 15 18.5KW Spindle Power 8 Tool Post Stations

ST32 CNC Turning Center With 15 18.5KW Spindle Power 8 Tool Post Stations

ST32 CNC Turning Center

18.5KW CNC Turning Center

8 Station multi axis turning center

Place of Origin:

China

Brand Name:

ShangJie PM

Certification:

CE ISO certification

Model Number:

ST32

Chat Now
Request A Quote
ST32 CNC Turning Center With 15 18.5KW Spindle Power 8 Tool Post Stations
Product Details
Machining Capacity:
Medium Duty
Spindle Power:
15/18.5KW
Condition:
New
Core Components:
Motor
Warranty:
12months
Key Selling Points:
High Productivity
Number Of Axes:
2
Tool Capacity:
12
Structure:
Slant Bed Lathe
Z Axis Travel:
500mm
Tool Post Stations:
8
Port:
Any Port In China
Chuck Size:
10 Inches
Spindle Motor Power:
11kw
Cnc Or Not:
CNC
Highlight:

ST32 CNC Turning Center

,

18.5KW CNC Turning Center

,

8 Station multi axis turning center

Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
The wooden case，Tin trunk ,Other seaworthy packing
Delivery Time
45-60 days
Payment Terms
T/T,L/C,,Western Union
Supply Ability
45-60 days
RELATED PRODUCTS
Good price PT36 2 Axes CNC Turning Center 5000kg Weight 500mm Z Axis For Precision Machining online Video

PT36 2 Axes CNC Turning Center 5000kg Weight 500mm Z Axis For Precision Machining

Chat Now
Good price PT-Series CNC Gang Tool Lathe with HT300 Grade Cast Iron 8 in Chuck and 25x25mm Tool Holder online

PT-Series CNC Gang Tool Lathe with HT300 Grade Cast Iron 8 in Chuck and 25x25mm Tool Holder

Chat Now
Good price Light Duty CNC Turning Center With 380V 220V 4 Milling Heads For Multi Purpose Metal Working online Video

Light Duty CNC Turning Center With 380V 220V 4 Milling Heads For Multi Purpose Metal Working

Chat Now
Good price Horizontal High Precision Slant Bed CNC Lathe Machine With 350mm Tailstock Travel online Video

Horizontal High Precision Slant Bed CNC Lathe Machine With 350mm Tailstock Travel

Chat Now
CONTACT US
86--15221502418
bear02@shanjmc.com
Chat Now
Product Description
ST32 CNC Turning Center with 15/18.5KW Spindle Power 8 Tool Post Stations and 10 inches Chuck Size
The ST Series from ShangJie PM offers slant-bed CNC lathes equipped with linear turret systems for enhanced rigidity and cutting precision. Designed for medium-to-high volume production, these machines deliver excellent chip evacuation and stable machining at high speeds.
Key Features
  • Slant-bed structure for efficient chip flow and stable operation
  • Linear turret enables fast tool indexing and smooth finishing
  • Ideal for high-precision turning in batch production environments
  • Excellent for processing shafts, bushings, and threaded components
  • Suitable for automotive parts, industrial tools, and hardware manufacturing
Construction Details
  • Casting Material: Machine bed constructed with HT300 grade cast iron as a monolithic casting, processed through vibration aging and double tempering treatments to eliminate residual stresses
  • Bed Structure: Monoblock design with low center of gravity, optimized using Finite Element Analysis (FEM) for maximum rigidity in heavy-duty cutting operations
Technical Specifications
Machine Type ST32
Max. swing diameter 470mm
Max. machining diameter on the saddle 120mm
Max. bar through diameter 28mm
Spindle nose A2-4
Spindle motor power 4KW
Spindle bore 38mm
Max. spindle speed 4000r/min
X axis 330mm
Z axis 270mm
X axis rapid feed speed 25m/min
Z axis rapid feed speed 25m/min
X axis Max. torque of motor 18N.m
Z axis Max. torque of motor 18N.m
Manual chuck 6"
Hydraulic clamping Chuck Size 6"
4-station electric knife holder OD tool size: 16x16mm
Machine size (L x W x H) 1500x1350x1600mm
Standard weight 1500KG
Expandable Functions
Modular Power Head: Customized power head configurations can be added according to processing requirements, enabling drilling, milling, tapping, and other feature machining operations.
ST32 CNC Turning Center With 15 18.5KW Spindle Power 8 Tool Post Stations 0 ST32 CNC Turning Center With 15 18.5KW Spindle Power 8 Tool Post Stations 1 ST32 CNC Turning Center With 15 18.5KW Spindle Power 8 Tool Post Stations 2 ST32 CNC Turning Center With 15 18.5KW Spindle Power 8 Tool Post Stations 3
Turn-Mill Capability: Can be configured with servo turret or multiple power heads for high-end turning-milling capabilities, meeting complex machining demands while minimizing equipment costs.
ST32 CNC Turning Center With 15 18.5KW Spindle Power 8 Tool Post Stations 4 ST32 CNC Turning Center With 15 18.5KW Spindle Power 8 Tool Post Stations 5 ST32 CNC Turning Center With 15 18.5KW Spindle Power 8 Tool Post Stations 6
Frequently Asked Questions
Q: Manufacturer or trading company? Where is the company located?
A: We are a professional manufacturer of CNC lathes, located in Shiyan City, Hubei Province.
Q: How long have you been involved in this market?
A: We have been engaged in the auto parts industry for 10 years.
Q: Can you provide a product catalog?
A: Contact our business manager, we will send the product catalog you need to your mailbox.
Q: About the terms and conditions of payment.
A: When you quote, we will confirm with you the trading method (FOB, CIF, CNF, etc.). For mass production we typically require 30% advance payment with balance due upon bill of lading. Payment methods are primarily T/T, though L/C is also acceptable.
Q: Product after-sales service scope and service period?
A: We offer a one-year warranty and 24-hour lifetime technical support.
