VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM

VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM

VS140 cnc vertical milling center

12000RPM cnc vertical milling center

8000RPM large vertical machining centers

Place of Origin:

China

Certification:

CE ISO certification

Chat Now
Request A Quote
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM
Product Details
Table Size:
600mm X 400mm
Weight:
6,500kg
Spindle Speed:
10,000 RPM
Type:
Vertical Machining Center
Power Supply:
3 Phase, 220V/380V/415V
Spindle Taper:
BT40
Controller:
Fanuc/Mitsubishi/Siemens
Max Load Capacity:
300kg
Warranty:
1 Year
Number Of Axes:
3
Tool Capacity:
24
Rapid Traverse Rate:
30m/min
Dimensions:
2,500mm X 2,000mm X 2,500mm
Highlight:

VS140 cnc vertical milling center

,

12000RPM cnc vertical milling center

,

8000RPM large vertical machining centers

Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
The wooden case，Tin trunk ,Other seaworthy packing
Delivery Time
45-60 days
Payment Terms
T/T,L/C,,Western Union
Supply Ability
45-60 days
RELATED PRODUCTS
Good price VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM online Video

VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM

Chat Now
Good price VMC850 CNC Turning Center With HT300 High Grade Casting 3 Phase 220V 380V 415V online Video

VMC850 CNC Turning Center With HT300 High Grade Casting 3 Phase 220V 380V 415V

Chat Now
Good price VS150 Heavy Duty CNC Vertical Center 3 Axes 30m/Min Rapid Traverse Rate 3 Phase online Video

VS150 Heavy Duty CNC Vertical Center 3 Axes 30m/Min Rapid Traverse Rate 3 Phase

Chat Now
Good price HT300 High Grade Castings CNC Vertical Center For Precision Milling High Speed Spindle online Video

HT300 High Grade Castings CNC Vertical Center For Precision Milling High Speed Spindle

Chat Now
CONTACT US
86--15221502418
bear02@shanjmc.com
Chat Now
Product Description
VS140 Vertical Machining Center with HT300 High-Grade Castings Precision Grade P Roller-Type Linear Guide and 8000/12000 RPM Spindle Speed
Product Overview
The VS series is a heavy-duty vertical machining center designed for superior performance. Featuring 6 sliders on the X-axis, 4 roller linear guides with 8 sliders on the Y-axis, and an expanded Z-axis column installation foot span, this machine provides exceptional stability and processing capabilities.
Machine Structure
The VS series is engineered with a low center of gravity, anti-distortion design, and heavy cutting capabilities for high material removal rates. Finite element analysis (FEM) optimizes the reinforcing ribs of HT300 high-grade castings, ensuring excellent dimensional stability and durability.
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 0
Key Structural Features
  • Standard spindle counterweight system reduces Z-axis load and thermal elongation
  • Large span Z-axis column for superior vibration damping and stability
  • HT300 material castings with vibration aging and secondary tempering processes
  • Reinforced Y-axis base and Z-axis column for heavy cutting applications
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 1 VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 2
Technical Specifications
Specification VS140
Workbench size 1400x800 mm
Workbench T-slot (number - size * pitch) 5-18x135 mm
Max. load capacity of the workbench 1400KG
X-axis travel distance 1410mm
Y-axis travel distance 810mm
Z-axis travel distance 710mm
Distance from spindle center to column guide rail 850mm
Spindle face to worktable surface distance 130-840 mm
Guide rail form Precision Grade P roller-type linear guide
X,Y,Z fast movement speed 30m/min
Max. spindle speed 8000/12000 rpm
Spindle taper hole BT40 (BT50 Optional)
Spindle motor power 15/18 KW
Tool magazine capacity Disc-Type 24Tools
Machine size (L x W x H) 2720x2580x2800mm
Standard weight 13500KG
Machine Tool Configuration
CNC system: FANUC, Siemens, SYNTEC, KND, Mitsubishi
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 3 VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 4
High-quality spindle with imported bearings
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 5
THK, PMI, HIWIN, HTPM 45,55 Precision Grade P roller-type linear guide
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 6
THK, PMI, HIWIN C3 grade Ø50 precision ground ball screw
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 7
High-quality tool clamping cylinder
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 8
NSK, SKF, FAG P4 grade imported angular contact paired bearings
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 9
Precision high-rigidity coupling
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 10
Imported high-torque synchronous belts
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 11
Additional Features
High-quality disc-type/Umbrella-type ATC Tool magazine
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 12 VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 13
Standard chain-type chip conveyor with small iron chip cart
VS140 CNC Vertical Milling Center With HT300 High Grade Castings Precision 8000 12000RPM 14
Company Advantages
Our company has passed quality system certification and possesses independent design and R&D capabilities. We operate large gantry machining centers, five-axis machining centers, and other advanced equipment, supported by a dedicated after-sales service team.
Product Advantages
  • HT300 high-grade castings with ergonomic design
  • Imported functional components for long-term dimensional stability
  • Complete in-house processes from casting to sheet metal fabrication
  • Strict quality control throughout manufacturing
Application Scenarios
Ideal for mechanical processing in automotive manufacturing, aerospace, and shipbuilding industries.
Frequently Asked Questions
Q: Manufacturer or trading company? Where is the company located?
A: We are a professional manufacturer of CNC lathes, located in Shiyan City, Hubei Province.
Q: How long have you been involved in this market?
A: We have been engaged in the auto parts industry for 10 years.
Q: Can you provide a product catalog?
A: Contact our business manager for the product catalog via email.
Q: About the terms and conditions of payment.
A: We offer various payment methods including T/T and L/C, typically with 30% advance payment.
Q: Product after-sales service scope and service period
A: We offer a one-year warranty and 24-hour lifetime technical support.
