High-precision CNC Turning Center with Max Turning Length 500mm Maxswing Over Bed Φ700mm and Max Processing Length 1000mm
The ET Series by ShangJie PM features compact, flat-bed CNC lathes with gang tool setups, engineered for small part precision turning. These machines are ideal for mass production of standard components such as screws, pins, bushings, and sleeves. Designed with high-speed linear guides and stable casting structures, the ET Series offers fast tool changes and reduced machining time.
- Compact flat-bed layout for streamlined small-part machining
- Gang tool system improves productivity and shortens cycle time
- Suited for standard parts manufacturing in large volumes
ET04D / ET05D
The machine tool structure adopts an integral bed with a low center of gravity design. The wide and thick-walled bed base can significantly reduce the vibration generated by the machine tool during high-speed and heavy cutting, improving the machining accuracy of precision parts.
By using finite element analysis (FEM), the shape and position of the reinforcing ribs of the casting are optimized to achieve the optimal strength of the bed. This makes the bed structure more suitable for heavy cutting and increases the service life of the cutting tools.
facebook line twitter whatsapp pinterest tumblr linkedin
Specifications
| Machine Type |
ET04D / ET05D |
| Max. swing diameter |
530mm |
| Max. machining diameter on the saddle |
120mm |
| Max. bar through diameter |
36mm |
| Spindle nose |
A2-4 / A2-5 |
| Spindle motor power |
5.5-12 KW |
| Spindle bore |
45mm |
| Max. spindle speed |
6000r/min |
| X1 axis |
500mm |
| X2 axis |
500mm |
| Z1 axis |
430mm |
| Z2 axis |
400mm |
| X axis rapid feed speed |
25m/min |
| Z axis rapid feed speed |
25m/min |
| X axis Max. torque of motor |
18N.m |
| Z axis Max. torque of motor |
18N.m |
| Pneumatic clamping |
Spring collet |
| Hydraulic clamping Chuck Size |
5" |
| Machine size (L x W x H) |
2400x1350x1600mm |
| Standard weight |
3550KG |
Machine Characteristics
Both the main and auxiliary spindles adopt permanent magnet synchronous electric spindles, which have high power and strong force, without belt drive. This enhances the dimensional stability of the machine tool during high-speed turning and further improves the surface finish of the workpiece. The spindle guide rails use large-sized and high-precision roller linear guides, which not only ensure the machining rigidity of the machine tool but also improve its machining accuracy. Combined with the corresponding power head, it can achieve turning and milling compound functions, enabling the completion of all processing procedures for complex parts of customers in a single clamping.
Frequently Asked Questions
Q: Manufacturer or trading company? Where is the company located?
A: We are a professional manufacturer of CNC lathes, located in Shiyan City, Hubei Province.
Q: How long have you been involved in this market?
A: We have been engaged in the auto parts industry for 10 years.
Q: Can you provide a product catalog?
A: Contact our business manager, we will send the product catalog you need to your mailbox.
Q: About the terms and conditions of payment.
A: When you quote, we will confirm with you the trading method (FOB, CIF, CNF, etc.). For mass production we typically require 30% advance payment with balance due upon bill of lading. Payment methods are primarily T/T, though L/C is also acceptable.
Q: Product after-sales service scope and service period?
A: We offer a one-year warranty and 24-hour lifetime technical support.
