VT1000 Vertical Turning Machine
Professional VT Series Machine Tools
The VT series machine tools are professionally designed with a focus on low center of gravity, anti-twist capability, heavy cutting performance, and high material removal efficiency. Featuring a box-type base and widened, thickened Z-axis columns, these machines deliver exceptional rigidity.
Through finite element analysis (FEM), we've optimized the reinforcing rib structure of castings to achieve maximum bed strength. Special reinforcement for the spindle base and Z-axis crossbeam enhances stability and prevents deformation.
Premium Casting Material
Machine castings utilize HT300 high-grade material with vibration stress relief and secondary tempering processes to eliminate internal stress. This results in:
- High strength and deformation resistance
- Excellent shock absorption capacity
- Long-term precision stability
Technical Specifications
| Parameter |
Value |
| Machine Type |
VT1000 |
| Max. swing diameter |
1100mm |
| Max. turning diameter |
1020mm |
| Max. turning height |
820mm |
| Spindle nose |
A2-15 |
| Spindle motor power |
22/26 KW |
| Max. spindle speed |
1500r/min |
| Chuck Size |
15"~ 32"(Optional) |
| X axis travel |
-50,+550mm |
| Z axis travel |
850mm |
| X axis rapid feed speed |
20m/min |
| Z axis rapid feed speed |
20m/min |
| Machine dimensions (L x W x H) |
2600x3500x4500mm |
| Standard weight |
14500KG |
Turn-Mill Functionality
The machine can be equipped with a servo power tool turret and various power heads to achieve turning-milling compound functions, meeting complex part processing requirements and improving efficiency.
Precision Installation Surface
The manual scraping process on installation surfaces ensures long-term maintenance of initial accuracy while enhancing machine rigidity, anti-vibration performance, and processing stability.
Application Advantages
The fully-enclosed stainless steel inner protective sheet metal design provides scientific layout, precision engineering, and superior sealing for reliable waterproof and oil-resistant performance.
Company Capabilities
Our quality-certified facility features independent R&D capabilities and is equipped with large gantry machining centers, five-axis machining centers, and vertical machining centers. Our dedicated service team provides efficient after-sales support.
Product Advantages
- HT300 high-grade castings with ergonomic design
- Selected imported functional components
- Long-term dimensional stability
- Complete in-house manufacturing from casting to sheet metal
Application Scenarios
Ideal for automotive manufacturing, aerospace, shipbuilding, and other precision mechanical processing fields.
Frequently Asked Questions
Q: Manufacturer or trading company? Where is the company located?
A: We are a professional CNC lathe manufacturer located in Shiyan City, Hubei Province.
Q: How long have you been involved in this market?
A: We have 10 years of experience in the auto parts industry.
Q: Can you provide a product catalog?
A: Contact our business manager for the required product catalog via email.
Q: About the terms and conditions of payment.
A: We confirm payment terms (FOB, CIF, CNF) during quotation. For mass production, we typically require 30% advance payment with balance upon bill of lading, accepting T/T or L/C.
Q: Product after-sales service scope and service period?
A: We provide a one-year warranty and lifetime 24-hour technical support.
