VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM

VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM
VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM
VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM

Large Image :  VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM

Product Details:
Place of Origin: China
Certification: CE ISO certification
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: The wooden case，Tin trunk ,Other seaworthy packing
Delivery Time: 45-60 days
Payment Terms: T/T,L/C,,Western Union
Supply Ability: 45-60 days
Contact Now Chat Now

VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM

Description
Y-Axis Travel: ±51 Mm Max Turning Length: 406 Mm
Max Swing: 508 Mm Rapid Traverse Rates: 30.5 M/min
Spindle Speed: 6000 RPM X-Axis Travel: 203 Mm
Z-Axis Travel: 406 Mm Model: ST-10Y
Turret Capacity: 12 Stations Weight: 6350 Kg
Max Turning Diameter: 406 Mm Power Requirement: 20 HP
Control: Haas CNC
Highlight:

VT800 CNC Vertical Turning Center

,

2000r/Min CNC Vertical Turning Center

,

6000RPM cnc vertical turning center machine

VT800 CNC Vertical Turning Center with HT300 High-Grade Castings 18.5/22 KW Spindle Motor Power and 2000r/min Spindle Speed

The VT series machine tools are professionally engineered with a focus on low center of gravity, anti-twist capability, heavy cutting performance, and high material removal efficiency. Featuring a box-type base and reinforced Z-axis columns, these machines deliver exceptional rigidity throughout operation.

Through finite element analysis (FEM), we've optimized the reinforcing rib structure of castings to achieve maximum bed strength. Special reinforcement for the spindle base and Z-axis crossbeam enhances stability and prevents deformation during operation.

Key Features
  • Casting Material: HT300 high-grade castings undergo vibration stress relief and secondary tempering processes to eliminate internal stress, ensuring long-term precision stability, high strength, and superior shock absorption.
VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM 0
Technical Specifications
Machine Type VT800
Max. swing diameter 920mm
Max. turning diameter 820mm
Max. turning height 720mm
Spindle nose A2-11
Spindle motor power 18.5/22 KW
Max. spindle speed 2000r/min
Chuck Size 15" / 18"(Optional)
X axis travel -50,+450mm
Z axis travel 740mm
X axis rapid feed speed 20m/min
Z axis rapid feed speed 20m/min
X axis Max. torque of motor 69N.m
Z axis Max. torque of motor 85.2N.m
Servo Tool Turret 8 Tools
OD tool size 32x32mm
Boring tool diameter ￠50 mm
Power turret tool size ER32
Air source pressure 0.5-0.8MPa
Machine size (L x W x H) 2000x3400x3650mm
Standard weight 9600KG
Expandable Functions

Turn-Mill Capability: Can be equipped with servo power tool turret and various power heads for turning-milling compound operations, solving complex part processing requirements and improving efficiency.

VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM 1

Precision Installation: Manual scraping process on installation surfaces ensures long-term maintenance of initial accuracy while enhancing rigidity, anti-vibration performance, and processing stability.

VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM 2
Application Advantages

The VT800 features a fully-enclosed stainless steel inner protective sheet metal design with scientific layout and superior sealing for reliable waterproof and oil-resistant performance during operation.

VT800 CNC Vertical Turning Center 2000r/Min Spindle Speed 12 Stations 6000RPM 3
Company Advantages
  • Quality system certified manufacturer
  • Independent design and R&D capabilities
  • Equipped with large gantry machining centers, five-axis machining centers, and other advanced equipment
  • Dedicated after-sales service team
Product Advantages
  • HT300 high-grade castings with ergonomic design
  • Selected imported functional components
  • Complete in-house processes from casting to sheet metal fabrication
  • Long-term dimensional stability without deformation
Application Scenarios

Ideal for automotive manufacturing, aerospace, shipbuilding, and other mechanical processing fields.

Frequently Asked Questions
Q: Manufacturer or trading company? Where is the company located?
A: We are a professional manufacturer of CNC lathes, located in Shiyan City, Hubei Province.
Q: How long have you been involved in this market?
A: We have been engaged in the auto parts industry for 10 years.
Q: Can you provide a product catalog?
A: Contact our business manager, we will send the product catalog you need to your mailbox.
Q: About the terms and conditions of payment.
A: When you quote, we will confirm with you the trading method (FOB, CIF, CNF, etc.). For mass production we typically require 30% advance payment with balance due upon bill of lading. Payment methods are primarily T/T, though L/C is also acceptable.
Q: Product after-sales service scope and service period?
A: We offer a one-year warranty and 24-hour lifetime technical support.
