HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench
HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench

Large Image :  HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench

Product Details:
Place of Origin: China
Certification: CE ISO certification
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: The wooden case，Tin trunk ,Other seaworthy packing
Delivery Time: 45-60 days
Payment Terms: T/T,L/C,,Western Union
Supply Ability: 45-60 days
Contact Now Chat Now

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench

Description
Power_Requirement: AC 220V/380V, 50/60Hz Pallet_Change_Time: 6 Seconds
Maximum Tapping Diameter: Φ20 Warranty: 1 Year
Spindle_Speed: 10,000 RPM Rapid_Traverse_Rate: 60 M/min
Suitable For: Various Box Parts Rough Finishing Main Motor Power: 15/18.5kw
Processing Capabilities: High Precision And High Efficiency Table Surface Type: T-slot
Control System: GSK SIEMENS FANUC Table Graduation: 1°*360
Table_Size: 500mm X 500mm Max_Load_Capacity: 500kg
Tool_Capacity: 30 Tools
Highlight:

HMC800 Horizontal Machining Center

,

800 X 800mm Horizontal Machining Center

,

380V horizontal milling center

HMC800 Horizontal CNC Milling Machine with 800x800 mm Workbench 2000KG Max Load and 1400mm X-axis Travel

The HMC series of machine tools features an advanced T-shaped integral bed structure with gantry-type column and front-hung box layout, delivering exceptional rigidity and precision retention. Designed for industrial applications, the HMC800 excels in heavy cutting operations with high material removal efficiency.

Machine Structure

Professionally engineered with low center of gravity design, anti-twist and anti-rust properties, the machine incorporates finite element analysis (FEM) to optimize casting reinforcement for maximum bed strength. Special reinforcement structures on the Y-axis base and column enhance heavy cutting capability and extend tool life.

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench 0
Specifications
Machine Type HMC800
Workbench size 800x800 mm
Workbench T-slot 7-18x100 mm
Max. load capacity 2000KG
X-axis travel distance 1400mm
Y-axis travel distance 1000mm
Z-axis travel distance 1100mm
Spindle speed 6000 rpm
Spindle taper BT50
Tool magazine capacity 30 Tools (Disc-Type)
Positioning accuracy 0.012mm
Repeat positioning accuracy 0.008mm
Machine dimensions 5300x4100x3100mm
Weight 19000KG
Machine Tool Configuration

CNC system: FANUC, Siemens, SYNTEC, KND, Mitsubishi

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench 1 HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench 2

High-quality spindle with imported bearings

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench 3

Precision linear guides: THK, PMI, HIWIN, HTPM 45,55 Precision Grade P roller-type

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench 4

Standard lift-free turntable with continuous positioning and indexing to 0.001°

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench 5

Double lead precision worm gear for zero clearance transmission with 20,000-hour maintenance-free lifespan

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench 6

Imported P4 grade precision turntable bearings with three-row roller design for superior clamping torque

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench 7

Standard chain-type chip conveyor with small iron chip cart

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench 8

High-quality disc-type/umbrella-type ATC tool magazine

HMC800 CNC Milling Horizontal Machining Center With 800 X 800mm Workbench 9
About Shanjmc

As a leader in precision machinery manufacturing, Shanjmc is dedicated to advancing industrial standards with innovative solutions. Our machines are crafted from high-grade materials to ensure strength, deformation resistance, and excellent shock absorption.

Contact us today to upgrade your industrial operations with our precision equipment.

Frequently Asked Questions
Q: Who are we?
A: Hubei Shangjie Precision Machinery Manufacturing Co., Ltd., a leading manufacturer of precision surface grinding machines and CNC equipment.
Q: How do we guarantee quality?
A: Through rigorous manufacturing processes using premium materials and comprehensive quality control measures.
Q: What products do we offer?
A: Precision surface grinding machines, CNC turning centers, machining centers, and custom automation solutions.
Q: What is our after-sales service policy?
A: We offer a one-year warranty and lifetime technical support for all our machines.
