HV5F-630 Five Sided Machining Center With 6000 8000RPM Spindle BT50 Taper Hole

The HV5F series machine tools feature a fixed gantry column integral bed structure with a large-span H-shaped gantry column and front-hung box layout. Combined with a wide, heavy four-roller linear guide base, these machines offer exceptional rigidity and precision retention. Designed for low center of gravity and anti-twist performance, they are optimized for heavy cutting applications.

The HV5F series incorporates finite element analysis (FEM) to optimize casting reinforcement rib placement, achieving maximum bed strength. The base and Y-axis column receive special reinforcement for enhanced heavy cutting capability and extended tool life.

Standard equipped with a lift-free turntable capable of continuous positioning and indexing to 0.001°. The entire series features a slider direct connection structure for high rigidity and precision.

The double lead precision worm gear achieves zero clearance transmission with a maintenance-free lifespan of 20,000 hours. Features large transmission ratio, smooth operation, and self-locking properties ideal for milling.

Imported P4 grade precision turntable bearings with three rows of rollers provide exceptional axial and radial support, delivering strong clamping torque and anti-overturning capability.

Standard equipment includes chain-type chip conveyor and small iron chip cart.

High-quality disc-type/Umbrella-type ATC Tool magazine
