HV5F-800 Five-Sided Machining Center with 6000 rpm Spindle BT50 Taper and 24-Tool Magazine
HV5F series machine tools adopt a fixed gantry column integral bed structure, featuring a large-span H-shaped gantry column and front-hung box layout. Coupled with a wide and heavy four-roller linear guide layout base, these machine tools offer exceptional rigidity and precision retention. The entire machine is professionally designed with a low center of gravity, anti-twist properties, and optimized for heavy cutting applications.
Machine Structure
Finite element analysis (FEM) optimizes the reinforcing ribs of castings, achieving optimal bed strength. The base and Y-axis column are specially reinforced for heavy cutting operations, extending tool life.
Specifications
| Machine Type |
HV5F-800 |
| Workbench size |
800*800 mm |
| Workbench T-slot (number - size * pitch) |
7-18*100 mm |
| Max. load capacity of the workbench |
2000KG |
| Horizontal Machining Section |
| X-axis travel distance |
1400mm |
| Y-axis travel distance |
800mm |
| Z-axis travel distance |
800mm |
| Distance from spindle centerline to worktable surface |
-50-750mm |
| Distance from spindle face to worktable center |
-60-740 mm |
| Vertical Machining Section |
| Z-axis travel distance |
800mm |
| Distance from spindle centerline to worktable surface |
150-950mm |
| Distance from spindle face to worktable center |
-230-570 mm |
| Guide rail form |
Precision Grade P roller-type linear guide |
| X,Y,Z fast movement speed |
24m/min |
| X axis Max. torque of motor |
69N.m |
| Y axis Max. torque of motor |
85.2N.m |
| Z axis Max. torque of motor |
85.2N.m |
| Max. spindle speed |
6000 rpm |
| Spindle taper hole |
BT50 |
| Spindle motor power |
15/18 KW |
| Tool magazine capacity |
Disc-Type 24Tools |
| Max. weight of cutting tools |
15KG(BT50) |
| Air source pressure |
0.5-0.8 MPa |
| Positioning accuracy |
0.012mm |
| Repeatability positioning accuracy |
0.008mm |
| Positioning accuracy of B-axis |
10" |
| Repeatability positioning accuracy of B-axis |
6" |
| Machine size (L * W * H) |
5300*4100*3100mm |
| Standard weight |
19000KG |
Machine Tool Configuration
CNC System Options
FANUC, Siemens, SYNTEC, KND, Mitsubishi
High-Quality Spindle
Imported bearings for superior performance
Precision Guide Rails
THK, PMI, HIWIN, HTPM 45,55 Precision Grade P roller-type linear guides
Standard equipped with a lift-free turntable, continuous positioning and indexing can reach 0.001°. The entire series adopts a slider direct connection structure, featuring high rigidity and precision.
Precision Worm Gear Transmission
Double lead precision worm gear achieves zero clearance transmission with 20,000-hour maintenance-free lifespan. Features large transmission ratio and self-locking properties ideal for milling operations.
Turntable Bearings
Imported P4 grade precision turntable bearings with three rows of rollers provide exceptional axial and radial support, offering large clamping torque and strong anti-overturning capability.
Chip Management System
Standard equipped with chain-type chip conveyor and small iron chip cart.
Tool Magazine Options
High-quality disc-type/umbrella-type ATC tool magazine
