Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center

Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center

Gmc6032 Gantry Machining Center

Gmc6032 BT50 Spindle Gantry Machining Center

Gantry Machining Center High-Accuracy

Place of Origin:

Hubei, China

Brand Name:

Shangjie Precision Machinery

Chat Now
Request A Quote
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
Product Details
Spindle Taper:
BT50
No. Of Spindles:
1
Type:
Gantry
Dimension(l*w*h):
1700*580*560
Weight (t):
70
Table Size:
2500*6000
Cnc Control System:
GSK
Table Travel (x) (mm):
6000
Table Travel (y) (mm):
3200
Table Travel (z) (mm):
1000
Positioning Accuracy:
±0.01
Repeatability (x/y/z) (mm):
±0.005
Range Of Spindle Speed:
0 - 6000
Max. Table Load(kg):
28000
Min. Time Of Tool Change(s):
3
Tool Magazine Capacity:
24
Key Selling Points:
Multifunctional, Automatic, Competitive Price, High Safety Level, High-Accuracy, High Productivity, Long Service Life, Easy To Operate, Flexible Manufacturing, Digital
Warranty:
1 Year
Voltage:
380 V
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Machining Capacity:
Heavy Duty
Rapid Feed Speed:
10 - 15
Highlight:

Gmc6032 Gantry Machining Center

,

Gmc6032 BT50 Spindle Gantry Machining Center

,

Gantry Machining Center High-Accuracy

Payment & Shipping Terms
Minimum Order Quantity
1
Price
$225,000
RELATED PRODUCTS
Good price GMC3018 BT50 Automatic High-Accuracy Gantry Machining Center online

GMC3018 BT50 Automatic High-Accuracy Gantry Machining Center

Chat Now
Good price 5 Axis Gantry CNC Milling Machine-Large Machining Center for Large Parts online

5 Axis Gantry CNC Milling Machine-Large Machining Center for Large Parts

Chat Now
Good price 3 Axis High Speed Bridge Portal Gantry CNC Milling Machining Machine Center GMC2018 Metal Processing Gantry Machining Center online

3 Axis High Speed Bridge Portal Gantry CNC Milling Machining Machine Center GMC2018 Metal Processing Gantry Machining Center

Chat Now
Good price GMC6028 BT50 Spindle Automatic High-Accuracy Competitive Price Gantry Machining Center online

GMC6028 BT50 Spindle Automatic High-Accuracy Competitive Price Gantry Machining Center

Chat Now
Contact Us
86--15221502418
bear02@shanjmc.com
Chat Now
Product Description
Product descriptions from the supplier

High-Accuracy: Ensures precision machining with ±0.005 mm repeatability.

Competitive Price: Affordable yet powerful, ideal for cost-conscious manufacturers.

Heavy Duty: Built for robust performance handling heavy loads up to 28000 kg.

Easy To Operate: Simple setup and control for efficient production.

Multifunctional: Versatile for various machining tasks.

Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
About this supplier

Hubei Shangjie Precision Machinery Manufacturing Co., Ltd. is a leading manufacturer of high-precision machining equipment, established in 2007 with a 20,000m2 workshop. Specializing in CNC gantry machining centers, we offer ISO 9001-certified products with advanced quality control, including laser interferometers and HT300 castings. Our production includes CNC turning centers, grinding machines, and precision parts, supported by full industrial capabilities from design to assembly.

Company overview
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
Factory profile
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
Exhibition event
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
Certificate
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
Customization capabilities
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
Packaging & shipping specifications
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
FAQ
Gmc6032 BT50 Spindle High-Accuracy Automatic Gantry Machining Center
