ST-Series High-Precision CNC Slant Bed Linear Turret Lathe
The ST Series from ShangJie PM offers slant-bed CNC lathes equipped with linear turret systems for enhanced rigidity and cutting precision. Designed for medium-to-high volume production, these machines deliver excellent chip evacuation and stable machining at high speeds.
- Slant-bed structure for efficient chip flow and stable operation
- Linear turret enables fast tool indexing and smooth finishing
- Ideal for high-precision turning in batch production environments
ST46 CNC Lathe - High-Precision Machine
Casting Material: Machine bed is constructed with HT300 grade cast iron as a monolithic casting, processed through vibration aging and double tempering treatments to eliminate residual stresses. This ensures exceptional dimensional stability and long-term durability, guaranteeing consistent machining accuracy during extended operation.
Bed Structure: The machine tool's structural design features a monoblock bed with a low center of gravity. Finite Element Analysis (FEM) is employed to optimize the geometry and layout of reinforcing ribs in the cast components, maximizing bed rigidity. This configuration ensures superior performance in heavy-duty cutting operations while extending tool service life.
facebook line twitter whatsapp pinterest tumblr linkedin
Specifications
| Machine Type |
ST46 |
| Max. swing diameter |
500mm |
| Max. machining diameter on the saddle |
140mm |
| Max. bar through diameter |
38mm |
| Spindle nose |
A2-5 |
| Spindle motor power |
5.5KW |
| Spindle bore |
48mm |
| Max. spindle speed |
4000r/min |
| X axis |
415mm |
| Z axis |
340mm |
| X axis rapid feed speed |
25m/min |
| Z axis rapid feed speed |
25m/min |
| X axis Max. torque of motor |
18N.m |
| Z axis Max. torque of motor |
18N.m |
| Pneumatic clamping |
Spring collet |
| Manual chuck |
8" |
| Hydraulic clamping Chuck Size |
8" |
| OD tool size |
20x20mm |
| Machine size (L x W x H) |
1650x1420x1650mm |
| Standard weight |
1850KG |
Expandable functions of machine tools
Modular Power Head
Customized power head configurations can be added according to the customer's part processing requirements, enabling drilling, milling, tapping, and other feature machining operations.
Turn-Mill
The machine can be configured with a servo turret or customized with multiple power heads to deliver high-end turning-milling capabilities. This versatile solution meets complex machining demands while minimizing customers' capital expenditure on equipment.
Product Advantages
1. Unmatched Precision and Durability
The Shanjmc ST46 is a high-precision CNC lathe machine engineered for industrial excellence. Crafted with a robust HT300 grade cast iron bed, this CNC lathe ensures exceptional stability and durability, making it a top choice among CNC lathe suppliers and manufacturers. The monolithic casting undergoes vibration aging and double tempering treatments, eliminating residual stresses for superior dimensional stability.
2. Superior Performance for Complex Machining
Built with a low center of gravity, the ST46's monoblock bed structure is optimized using Finite Element Analysis (FEM) to enhance rigidity. This design ensures the CNC lathe machine delivers outstanding performance in demanding cutting operations, extending tool service life. The ST46 is equipped with a 5.5KW spindle motor, achieving speeds up to 4000r/min, and features a 4-station electric knife holder for versatile tooling options.
3. Scalable Solutions for Evolving Needs
The ST46 is not just a CNC lathe machine; it's a scalable solution designed to adapt to your growing demands. With customizable power head configurations, this CNC lathe can be tailored to specific part processing requirements, offering high-end turning-milling capabilities. This adaptability makes it a preferred option for manufacturers looking to minimize capital expenditure while maximizing operational efficiency.
4. Versatile Machining Capabilities
The ST46 offers expandable functions like modular power heads, enabling drilling, milling, and tapping. This versatility makes it a top choice among CNC lathes, meeting diverse machining needs with precision. Whether you're a small business or a large-scale operation, the ST46 provides the flexibility and performance needed to stay ahead in the competitive machining landscape.
5. Cost-Effective Investment
Investing in the Shanjmc ST46 means choosing a CNC lathe machine that offers both reliability and scalability. Its robust construction and adaptable features ensure long-term operational efficiency, making it a cost-effective choice for manufacturers and suppliers. With the ST46, you can maximize your ROI while minimizing capital expenditure.
About Us
Shanjmc is a leading manufacturer in the CNC lathe industry, renowned for its commitment to precision engineering and industrial excellence. Our ST-Series, including the ST46, exemplifies our dedication to delivering high-performance machinery that meets the rigorous demands of modern manufacturing. With a robust HT300 grade cast iron bed, our machines offer exceptional stability and durability, ensuring consistent machining accuracy even during extended operations.
We employ advanced techniques such as vibration aging and double tempering treatments to eliminate residual stresses, guaranteeing superior dimensional stability. Our innovative designs, optimized using Finite Element Analysis (FEM), enhance rigidity and performance in heavy-duty cutting operations, extending tool service life.
At Shanjmc, we understand the evolving needs of our clients, offering scalable solutions with customizable power head configurations for diverse machining tasks. Whether you're a small business or a large-scale operation, our CNC lathes provide the flexibility and efficiency needed to excel in the competitive machining landscape.
FAQ
Who are we?
We are Hubei Shangjie Precision Machinery Manufacturing Co., Ltd., a leading manufacturer and supplier of high-precision CNC lathe machines, dedicated to providing industrial excellence through innovative machining solutions.
How can we guarantee quality?
Our CNC lathes are crafted with robust HT300 grade cast iron beds, ensuring exceptional stability and durability. Each machine undergoes rigorous testing and quality control processes to guarantee consistent machining accuracy and reliability.
What can you buy from us?
You can purchase a wide range of CNC lathe machines, including the ST46 model, which offers unmatched precision and versatile machining capabilities for industrial applications.
Why should you buy from us not from other suppliers?
Our ST46 CNC lathe stands out due to its superior performance in heavy-duty cutting operations and expandable functions like modular power heads. We offer scalable solutions tailored to your specific needs, ensuring maximum operational efficiency.
What services can we provide?
We provide tailor-made automation solutions, comprehensive customer support, and customizable machine configurations to meet diverse machining requirements.
Can I customize this product for my business?
Yes, the ST46 CNC lathe offers customizable power head configurations, allowing you to tailor the machine to specific part processing requirements and enhance your production capabilities.
How fast can I receive my order?
We strive to ensure prompt delivery of your CNC lathe machine. Once your order is confirmed, we will provide an estimated delivery timeline based on your location and order specifications.
