Precision Surface Grinding Machine with HT300 High-Grade Material 0.008mm Grinding Accuracy and C3 Grade Ball Screws
CNC Grinding Machine
ShangJie PM's CNC grinding machines are engineered for high-precision surface finishing and contour grinding of metal components. Featuring rigid structures, high-accuracy servo systems, and advanced control interfaces, these machines deliver exceptional repeatability and ultra-smooth finishes on steel, cast iron, and hardened alloys.
Suitable for molds, tools, shafts, and complex mechanical parts, CNC grinders are widely applied in aerospace, automotive, die-making, and precision manufacturing. Their automation capabilities, programmable parameters, and fine-feed control make them ideal for tasks requiring micron-level accuracy.
- High-rigidity design ensures consistent surface precision
- Suitable for flat, angular, and complex contour grinding
- Ideal for high-precision applications in mold and tooling industries
PSG/GM series machine tool adopts a gantry structure, with enlarged column and crossbeam box structure support, ensuring excellent rigidity of the entire machine. The castings of the machine tool are made of HT300 high-grade material, which has high strength, strong resistance to deformation, and excellent shock absorption capacity. The grinding accuracy within a 3-meter travel can reach within 0.008mm. The minimum feed rate of the Z-axis is 0.001mm.
Machine castings are made of HT300 high-grade material and undergo vibration stress relief and secondary tempering processes to eliminate internal stress. They feature high strength, strong resistance to deformation, and excellent shock absorption capacity, ensuring that the machine tool maintains stable precision over long-term use.
Specifications
| Model |
PSG-2012GM |
PSG-3012GM |
PSG-4012GM |
PSG-2017GM |
PSG-3017GM |
PSG-4017GM |
PSG-3021GM |
PSG-4021GM |
| Workbench size (mm) |
2000x1000 |
3000x1000 |
4000x1000 |
2000x1400 |
3000x1400 |
4000x1400 |
3000x1600 |
4000x1600 |
| Model |
PSG-6021GM |
PSG-4026GM |
PSG-5026GM |
PSG-6026GM |
PSG-8026GM |
PSG-5032GM |
PSG-6032GM |
PSG-8032GM |
| Workbench size (mm) |
6000x1600 |
4000x2100 |
5000x2100 |
6000x2100 |
8000x2100 |
5000x2600 |
6000x2600 |
8000x2600 |
Machine Tool Configuration
The hydrostatic spindle has the advantages of high rotational accuracy, good rigidity, long service life and low noise. It can grind workpieces with high precision and high efficiency, and is an essential configuration for precision grinding machines.
The entire Adopting Japanese THK, German INA, Rexroth and Taiwan PMI SP grade ultra-precision linear guides.
The entire series of grinding machines adopt C3 grade high-precision ground ball screws, which operate smoothly without shock, have low wear and a long service life, effectively enhancing the working accuracy and stability of the machine tools.
The base of the electromagnetic chuck adopts steel plate milling cavity technology and all-copper coils. Compared with cast steel bases, it features a smaller volume and stronger magnetic force. The magnetic force is evenly distributed and adjustable, making it suitable for various heavy-duty and precision machining.
Product Advantages
1. Unmatched Precision and Rigidity
The Shanjmc PSG/GM Series precision surface grinding machine is crafted from HT300 high-grade material, ensuring exceptional rigidity and resistance to deformation. This surface grinding machine achieves grinding accuracy within 0.008mm over a 3-meter travel, making it ideal for grinding machine manufacturers seeking reliable performance.
2. Advanced Operational Features
Equipped with a hydrostatic spindle, the Shanjmc PSG/GM Series precision grinding machine offers high rotational accuracy and low noise, essential for high-efficiency grinding. The integration of ultra-precision linear guides ensures smooth operation and long service life.
3. Scalable Design for Versatility
The Shanjmc PSG/GM Series precision surface grinding machine is designed to adapt to future demands with its scalable design, accommodating various workbench sizes and load capacities.
4. Enhanced Production Efficiency
Featuring an electromagnetic chuck base with steel plate milling cavity technology and all-copper coils, this precision grinding machine provides adjustable magnetic force for quick clamping and release of workpieces.
5. Long-Term Value and Reliability
Available for bulk ordering, the Shanjmc PSG/GM Series precision surface grinding machine offers long-term value and reliability. Its durable construction ensures stable precision over extended use.
About Us
Shanjmc is a leader in precision machinery manufacturing, dedicated to advancing industrial standards with our innovative solutions. Our PSG/GM Series precision surface grinding machines are crafted from HT300 high-grade material, ensuring high strength, resistance to deformation, and excellent shock absorption.
FAQ
Who are we?
We are Hubei Shangjie Precision Machinery Manufacturing Co., Ltd., a leading manufacturer of precision surface grinding machines designed for industrial applications.
How can we guarantee quality?
We guarantee quality through rigorous manufacturing processes and the use of premium materials like HT300 high-grade castings.
What can you buy from us?
You can purchase a wide range of industrial equipment from us, including precision surface grinding machines, CNC turning centers, machining centers, and tailor-made automation solutions.
Why should you buy from us not from other suppliers?
Choosing Shanjmc means investing in unmatched precision and rigidity. Our machines feature advanced components like hydrostatic spindles and ultra-precision linear guides, ensuring high efficiency and long service life.
What services can we provide?
We offer comprehensive services including product customization, bulk ordering options, and tailor-made automation solutions.
Can I customize this product for my business?
Yes, our precision surface grinding machines can be customized to meet your specific business needs.
Do you offer wholesale pricing?
Absolutely, we provide competitive wholesale pricing for bulk orders.
